Explorer Step Over 26" E-bike
Free Shipping to Contiguous USA
Shipped out in 24h after receiving your payment, delivery within 5-7 business days via UPS.
All Troxus products are sent 100% free of charge to those living in the contiguous United States. We do not ship to Puerto Rico, Guam, Alaska, or Hawaii. We are currently unable to ship directly to PO Boxes or APOs.
24-Month Warranty
The Product is covered by our 18-Months warranty from date of receiving the goods, in accordance with our warranty policy.
15-Day Returns
You can return your bike within 15 days from date of purchase for a full refund, in accordance with our return policy.
QUESTIONS
Send us an email and we will get back to you ASAP: support@troxusmobility.com
Explorer - Your Adventure Partner
Life is meant to be explored. Troxus Explorer series e-bikes equipped with durable fat tires and a sturdy aluminum alloy frame provide more stability and traction over rough terrain like snow, sand, and mud. And with the 48V 20A high-power SAMSUNG battery, Explorer has enough power to ride and explore further.
Powerful Bafang 750W Motor
Troxus Explorer series fat tire E-bikes are equipped with the globally recognized BAFANG hub motor. This powerful 750W brushless motor efficiently delivers speeds up to 28MPH with pedal assist. You can enjoy your explorations with increased stability and smoothness throughout the rear hub’s power range.
48V 20A Lithium-ion Battery with SAMSUNG Cells
The Troxus Explorer series supports your long-distance needs with a high capacity battery. SAMSUNG lithium battery cells provide 60+ miles of range per charge, allowing you to discover more and ride further. These batteries are rigorously tested and are waterproof, so that they can reliably perform in any kind of weather- rain or shine.
Thermal Test
Impact Test
Overcharge Test
Forced Discharge Test
Shock Test
Vibration Test
26" x 4.0" Kenda All-Terrain Fat Tires
Troxus Explorer uses specifically designed e-bike fat tires made of extra-elastic rubber with lower pressure for great shock and vibration absorbency. They also provide excellent grip and easily shed mud, dirt, and sand. No matter whether you are riding in the Rocky Mountains or through the soft leafy litter of Yellowstone Park, or in which weather, you can ride without hesitation.
Tektro Hydraulic Disc Brakes
With a dual-diameter opposed piston design, these powerful hydraulic disc brakes have an increased contact area, providing excellent control and confidence in all conditions.
High-end Quality Components
Best Fit For Height: 5'4"-6'10"
REAL WORLD TESTING
ON THROTTLE
SPEED:
Up to 20MPH
RANGE:
36 Miles Without Pedaling
ON PEDAL ASSIST
PAS LEVEL
1
SPEED:10MPH
RANGE:65Miles
2
SPEED:15MPH
RANGE:60Miles
3
SPEED:20MPH
RANGE:38Miles
4
SPEED:23MPH
RANGE:36Miles
5
SPEED:28MPH
RANGE:34Miles
Speed & Range testing was calculated using a rider weight of 180lbs on 80% flat terrain
SPECIFICATION
MOTOR
Bafang 48V 750W Hub motor
THROTTLE
Throttle on demand-throttle from a complete stop
DISPLAY
L401 LCD
SPEED
Up to 20MPH on throttle and up to 28MPH on Pedal Assist
BATTERY
Removable Internal Lithium-ion 48V, 20Ah (960Wh)with Samsung cells
SENSORS
Speed Sensor
PEDAL ASSIST
5 Levels
CHARGER
54.6V 3A
RANGE
30-62 Miles
FRAME
6061 Aluminium Alloy
WEIGHT
Net Weight: 83.78LB
Gross Weight: 103.62LB
PEDALS
9/16" Alloy Platform
FORK
Aluminum Alloy, Suspension Fork
WEIGHT LIMIT
Standard Weight Limit 275LB
Maximum Weight Limit 353LB
KICKSTAND
Included, Rear Mount
BOTTOM BRACKET
Square Taper, Sealed
CRANKSET
170mm w/46T
REAR DERAILLEUR
Shimano 8 speed
CASSETTE
12-32T, 8 Speed Cassette
SHIFT LEVER
8 Speed
BRAKES
Tektro Hydraulic Disc Brake, 180mm Rotors
CHAIN
KMC Z8.3
RIM
Front: Single Wall Aluminum 36h
Rear: Double Wall Aluminum 36h
Rear: Double Wall Aluminum 36h
SPOKES
Front wheel: black stainless 13 Gauge
Rear wheel: black stainless 12 Gauge
Rear wheel: black stainless 12 Gauge
TUBES
Butyl Rubber
HUBS
Nutted Front and Rear
TIRES
26" x 4.0" Tires
SADDLE
Troxus
SEATPOST
Forged Alloy, 30.9*350mm, 2 Bolt Clamp
STEM
Threadless, 28.6mm, 7 Degree Rise
SEAT CLAMP
Quick Release
HANDLEBARS
Aluminum 31.8mm, 700mm
HEADSET
GINEYEA Sealed Bearing Headset
GRIPS
Ergonomic Comfort
PACKAGED
Above all accessories are included
GEOMETRY
| Frame Size | Standard (mm) |
| Wheel size | 26"*4.0 |
| A ─ Seat tube | 500 |
| B ─ Seat tube angle | 71.0° |
| C ─ Head tube length | 160 |
| D ─ Head angle | 69° |
| E ─ Effective top tube | 605 |
| F ─ Bottom bracket height | 296 |
| G ─ Bottom bracket drop | 70 |
| H ─ Chainstay length | 490 |
| I ─ Offset | 46 |
| J ─ Trail | 91.2 |
| K ─ Wheelbase | 1159.5 |
| L ─ Standover | 714.3 |
| M ─ Frame Reach | 405 |
| N ─ Frame Stack | 624.6 |
