Trax Mid-Drive E-Bike

Name: Trax Mid-Drive E-Bike
Brand: TROXUS
SKU: 10870100200
Price: 2099.0 USD
Availability: InStock
Rating: 4.8 (20 reviews)

$2,099.00 USD $3,299.00 USD

Interest-free installments:

Color:Radiant White

Frame:S - Low Step

Variant

At Troxus Mobility, our goal is to provide a best-in-class customer experience for everyone.

Our team is available Mon-Fri from 9am-4pm (PST).

Feel free to call us at (888) 905-8243 or submit a ticket below and we will respond within 1-2 business days.

UP TO 28 MPH

Max Speed

Stylish Performance

Hand crafted alloy frame with beautiful welds.

Power, Safety, And Range

Bafang® 500 watt mid-drive motor, with 720 Wh (15Ah) UL-certified battery, provides intuitive pedal assistance with all day range.

Our Most Comfortable All-Day Cruiser

Class 3 28mph model with Troxus Premium Comfort Cockpit, adjustable stem, swept back handlebars, ergonomic grips and wide plush saddle for all day riding comfort.

Never Miss A Shift

Shimano® CUES E-bike specific 11-speed wide range drivetrain for smooth shifting and gearing for all of your needs.

6061 Aluminum Frame With Clean Smooth Welds

Low-step and mid-step frame options to fit different rider sizes and needs.

Bafang® 500W Mid-Drive Motor

Ultra efficient 500W motor, with impressive power, and lighter weight.

48V / 15Ah 720Wh Battery

Incredible range and reliability, built with Samsung® cells, for up to 55 miles on a single charge.

Kenda® KwickSeven 27.5" x 2.2" Tires With Reflective Stripes

Efficient smooth tread tires with excellent puncture protection, and added visibility with reflective strips on sidewalls.

Suntour® Mobie 32 Suspension Fork With 75mm Travel

Lightweight suspension to take the sting out of roads or cycle paths.

Shimano® CUES M6100 11-spd Derailleur System

Shimano®'s e-Bike specific shifting system, for flawless shifting, even under full power.

*Prop 65 Warning: This product contains a chemical known to the State of California to cause cancer, birth defects or other reproductive harm.

*All specifications are subject to change without notice.

Explore the Performance in Person with Expert Recommendations

Find the perfect e-bike with expert guidance, then experience it firsthand with a test ride.

Find A Dealer Near Me

Motor

Bafang® 48V/500W Mid-Motor, 130Nm Max. Torque

Battery

UL-2771 Certified / Internal / Removable / Lithium Ion, 48V/15Ah (720Wh) with Samsung® Cells

Display

Bafang® Color Display, Bluetooth, w/ Multi-Function Remote

Throttle

Thumb Throttle on Handlebar

Sensor

Torque & Cadence Sensors included In Mid-Motor

Frame

Aluminum Frame

Fork

Suntour® Mobie 32 Suspension Fork, 75mm Travel, 15mm Thru-Axle

Chain

Shimano® 11-Speed

Crankset

Aluminum, Bafang® 42T, w/ Single Alloy Chainguard, Square Taper, 170mm

Rear Derailleur

Shimano® CUES, GS, 11-Speed

Max Speed

Up To 20 MPH on Throttle / Up To 28 MPH on Pedal Assist

Range

Up To 60 Miles Per Charge

Weight Limit

Maximum Load: 330 lbs

Net Weight

61 lbs

Rack

Alloy Rear Model

Recommend Height

Small Low-Step

5'0" - 5'7"

153 - 171 cms

Medium Low-Step

5'6" - 6'2"

168 - 185 cms

Large Mid-Step

5'8" - 6'4"

173 - 193 cms

Model

Low-Step

Mid-Step

Frame Size

Small / 15.5"

Medium / 17.5"

Large / 19"

Wheel Size

27.5"x2.2"

A - Seat Tube Length

394

445

483

B - Seat Tube Angle

73°

73˚

References

Manual - Trax Mid-Drive

Excellent Support and Solid Build Quality

There was a small cosmetic issue on arrival, but customer support responded quickly and handled it professionally. The bike itself feels sturdy and well-made, and the mid-drive motor delivers smooth, reliable power. Overall, I’m very happy with both the product quality and the service.

Assembly Took Some Time, Ride Is Worth It

I took some time during setup to make sure everything was adjusted correctly. Once assembled, the riding experience was excellent. The mid-drive motor feels responsive and makes climbing hills much easier than my previous bike. After several rides, I’m very satisfied with the performance and quality.

Smooth Mid-Drive Performance with a Cool Night Look

This bike rides incredibly smoothly thanks to the mid-drive system. You immediately feel the torque when pedaling, especially uphill. The integrated lighting adds visibility at night and gives the bike a premium look. It feels powerful, controlled, and well-designed. One of the most enjoyable mid drive electric bikes I’ve ridden.

Fun Ride with Responsive Support

The bike is fun to ride and feels powerful yet controlled. I had a question early on and customer support was responsive and helpful. After some initial adjustments, everything has been working well. The mid-drive system really shines on hills and longer rides.

Smooth, Quiet, and Easy to Ride

The mid-drive motor is quiet and delivers power naturally as you pedal. Assembly was straightforward, and everything worked perfectly out of the box. This mid drive ebike feels refined and easy to control, even on longer rides.
