Trax Sport E-Bike

*Prop 65 Warning: This product contains a chemical known to the State of California to cause cancer, birth defects or other reproductive harm.
*All specifications are subject to change without notice.
Jiabo® Hub-Drive Motor 36V/500W+ Peak Power, 50Nm Peak Torque
UL-2771 Certified / Internal / Removable / Lithium Ion, 36V/10Ah (360Wh) with Samsung® Cells, w/ Optional 252Wh Range Extender Battery (36V/7A)
Stem-Integrated Color Display, Bluetooth, w/ Turn Signals, w/ Multi-Function Remote
Thumb Throttle on Handlebar
Switchable Torque And Cadence Sensor Modes
0~5 Level Pedal Assist
2A / 100-240V Input / 42V Output
80 Lux Front Light, Rear Light w/ Turn & Hazard Signals
36Vx15A/12V
6061-T6 Aluminum Frame, Lightweight, Mid-Step & Step-Over
Rigid Aluminum, 700c, Tapered 1.5", Internal Front Brake Routing
KMC® 1/2"x3/32"
Aluminum, 46T, w/ Alloy Chainring & Single Chainguard, Square Taper, 170mm
Shimano® RD-M310-L, Altus, 8-Speed
Shimano® 8-Speed, 12-32T
Shimano® 8-Speed
Square Taper Sealed Bearings, Torque & Cadence Sensors Included
KENDA® K-1266 Urban 27.5"x1.75"
Alloy, 14Gx36H, O.L.D. 100mm, 3/8"Axle, w/ Nuts
Jiabo® 36V 350W+/ 25 MPH. 50Nm
Alloy Double Wall, 27.5"x2.0" w/ Eyelets
Stainless 14G. Front / 13G. Rear
Tektro® Hydraulic, w/ Brake Sensors
180mm / 160mm
Troxus Comfort / 195mm Wide
Alloy, 30.9x400mm, Adjustable
Alloy, 35mm w/ Quick Release
Alloy, Forged, Adjustable, w/ Integrated Display / Ext. 110mm, w/ Internal Cable Routing
Zoom® Alloy, 31.8mmx700mm Wide, 20mm Rise, 9 Deg. Backsweep
Ergonomic Comfort
9/16″ Alloy Platform with Reflectors
ICR Type, Threadless, Internal 57/62mm, w/ Internal Cable Routing
Max Speed Up To 20 MPH on Throttle / Up To 25 MPH on Pedal Assist
Up To 45 Miles Per Charge/ Up to 65 Miles w/ Range Extender
Maximum Load: 300 lbs. / Rider: 245 Lbs. / Rear Rack: 55 lbs.
47 lbs
Lightweight Alloy Rear Model / MIK-Compatible Rear Rack
Plastic 27.5"
Adjustable Side Kickstand
Above All Accessories Are Included.
5'0" - 5'5" (153 - 166cms)
5'5" - 5'10" (166 - 178cms)
5'9" - 6'4" (176 - 193cms)

Mid-Step
Step-Over
Step-Over
Small
Medium
Large
27.5"x1.75"
27.5"x1.75"
27.5"x1.75"
394
445
495
74˚
74˚
74˚
140
145
155
69˚
69˚
69˚
552
590
609
285
285
285
62
62
62
455
455
455
45
45
45
1082
1121
1141
388
425
441
571
576
585
0
0
0
420
420
420
