Sale price$1,699.00 USD
Interest-free installments:

Color:Red
Delivery:Version 2

CONTACT US

Our sales team and technicians will answer your questions within 1-2 business days. Our goal is customer satisfaction. We will do our best to understand and meet our customer's requirements at all times.

Available:
Phone: Mon-Fri 9am-5pm PT
Online Chat: Mon-Fri 9am-5pm PT

Address: 2485 Coral St Vista CA, 92081, United States

Pre-/After-sales: support@troxusmobility.com
Dealer: partner@troxusmobility.com
Amazon: amazon@troxusmobility.com
Cooperation Inquiries: pr@troxusmobility.com

Phone No:888-905-8243

troxus ebike

troxus ebike

750W Bafang Motor
Powerful Bafang 750W Motor
The powerful Bafang 750W hub motor is strong enough to handle every section of the trail, and gives you stable, smooth, intuitive power for supporting every pedal stroke along the way. Reliably delivers speeds up to 28 mph in pedal assist mode—while the throttle response quickly helps the rider enjoy the speed and freedom easily.
troxus
Affiliates
48V 20A Lithium-ion Battery with  SAMSUNG Cells
960Wh capacity battery gives you up to 50+ miles of riding on a single charge. The BMS battery management system regulates discharge and charge cycles to prolong battery life. Strict battery testing ensures the battery can safely work in extreme environments.
Thermal Test
Impact Test
Overcharge Test
Forced Discharge Test
Shock Test
Vibration Test
Affiliates
Affiliates
Kenda All-terrain Fat Tires reach compliant
Troxus Lynx uses specifically designed e-bike fat tires made of extra-elastic rubber with lower pressure for great shock and vibration absorbency. They also provide excellent grip and easily shed mud, dirt, and sand. No matter whether you are riding in the Rocky Mountains or through the soft leafy litter of Yellowstone Park, or in which weather, you can ride without hesitation.
troxus
26*4.0 Kenda All-Terrain Fat Tires
Tektro Hydraulic Disc Brake

Shimano 7 Speed Shifting Operation
Smooth and light action shifting for years of stress-free riding. Ergonomic shift lever shape for natural finger movement. The 7 gears allow riders to choose the precise gear that suits them and the riding terrain.
Tektro Hydraulic Disc Brake
High-end Quality Components

20" Kenda Fat Tires

The Kenda tire casings are made with a layer of aramid and ceramic particles built in under the tread area and along the sidewalls. This material forms a defensive barrier that can provide effective protection against punctures from glass and other small materials. Not only are they durable but they look great too!


Aluminum Alloy Frame

Lightweight and durable 6061 aluminum frame.


SHIMANO 7 Speed Gear Shift System

The Shimano 7 speed cassette means you can shift to larger gears for uphill riding and smaller gears for higher speeds. Combined with Pedal Assist, you can easily adjust the right speed for your ride.


Integrated Equipment

The Troxus Electric Bike is equipped with a rear rack therefore the bike can carry your cargo easily. What’s more, you can install a child seat and enjoy riding with your children.


Smart Display

With Lynx Smart Display you can easily check your stats like Speed, Battery, Assistance level, and Trip Distance. The large backlit LCD display lets you check the info at a glance so you can keep your eyes on the road.


Samsung Battery

A powerful motor needs a great battery and the Samsung 48V/20Ah battery is ready to deliver. It provides an estimated range of up to 50+ miles. This battery is also easily removable and very portable - you can take it with you on mid-ride stops, and thanks to its USB port it can be used to charge your phone and accessories.

Best Fit For Height: 5'1"-6'3"
Best Fit Height For : 5’11”-6’4”
REAL WORLD TESTING
ON THROTTLE

SPEED:
Up to 20MPH

RANGE:
33 Miles Without Pedaling
ON PEDAL ASSIST
PAS LEVEL
1
SPEED:9.5MPH
RANGE:58Miles
2
SPEED:12.5MPH
RANGE:50Miles
3
SPEED:16MPH
RANGE:36Miles
4
SPEED:20MPH
RANGE:34Miles
5
SPEED:26MPH
RANGE:32Miles
Speed & Range testing was calculated using a rider weight of 180lbs on 80% flat terrain
SPECIFICATION
MOTOR

Bafang 48V 750W hub motor

THROTTLE
Throttle on demand-throttle from a complete stop
DISPLAY
L401 LCD
SPEED
Up to 20MPH on Throttle and up to 28MPH on Pedal Assist
BATTERY
Removable Internal Lithium-ion 48V, 20Ah (960Wh)with Samsung cells
SENSORS
Speed Sensor
PEDAL ASSIST
5 Levels
CHARGER
54.6V 3A
RANGE
30-62 Miles
FRAME
6061 Aluminium Alloy
WEIGHT
Net Weight: 77.16LB
Gross Weight: 101.41LB
PEDALS
9/16" Alloy Platform
FORK
Aluminum Alloy, Suspension Fork
WEIGHT LIMIT
Standard Weight Limit 275LB
Maximum Weight Limit 353LB
KICKSTAND
Included, Rear Mount
BOTTOM BRACKET
Square Taper, Sealed
CRANKSET
165mm w/46T
REAR DERAILLEUR
Shimano 7 Speed
CASSETTE
14-28T, 7 Speed Cassette
SHIFT LEVER
7 Speed
BRAKES
Tektro M280 Mechanical Disc Brake
CHAIN
KMC Z7
RIM
Front: Single Wall Aluminum 36h
Rear: Double Wall Aluminum 36h
SPOKES
Front wheel: black stainless 13 Gauge
Rear wheel: black stainless 12 Gauge
TUBES
Butyl Rubber
HUBS
Nutted Front and Rear
TIRES
KENDA 20" 4.0"
SADDLE
Troxus
SEATPOST
Forged Alloy, 30.9*350mm, 2 Bolt Clamp
STEM
Threadless, 28.6mm,30 Degree Rise
SEAT CLAMP
Quick Release
HANDLEBARS
Aluminum 31.8mm, 620mm
HEADSET
GINEYEA Sealed Bearing Headset
GRIPS
Ergonomic Comfort
GEOMETRY
geometry
Frame Size Standard (mm)
Wheel size 20"*4.0
A ─ Seat tube 375
B ─ Seat tube angle 71°
C ─ Head tube length 145
D ─ Head angle 70°
E ─ Effective top tube 645
F ─ Bottom bracket height 286.5
G ─ Bottom bracket drop 10
H ─ Chainstay length 425
I ─ Offset 46
J ─ Wheelbase 1126.4
K ─ Frame Reach 450.4
L ─ Frame Stack 563.5

FAQ

Order and Payment

It doesn't take a long time to ship. And different place has different delivery time.

Returns and Refunds

Yes, we provide a 15-day return policy and a two-year warranty. If you are not satisfied with the product, you can return it within 15 days. Please NOTE that for a return, it's important to ensure that the original packaging is in good condition and the riding mileage should not exceed 10 miles. For more detailed warranty information, please refer to the product page, or feel free to contact our customer support team for assistance.

Product/Service-Related

The battery range varies depending on several factors, but typically, you can travel 30 to 60 miles on a single charge. Please note that riding conditions, speed, and payload can affect the range.

It is recommended to keep the tires inflated, lubricate the chain, and perform periodic brake checks. Additionally, the battery should be charged and stored properly to maintain performance. For more information, you can check out our Help Center.

In most areas, a driver's license or registration is not required to ride an e-bike, but regulations vary by region. Please check the regulations in your area before making a purchase.

The battery can be charged by plugging the provided charger into a standard electrical outlet. Charging time depends on the battery capacity and its current state, but typically takes several hours.

Yes, we offer a variety of accessories and upgrade options, such as front baskets, rear racks, lights, locks, and more, to cater to different riders' needs.

Yes, it is IPX5. But it's not suggested to ride in the rain.

You can find information about recommended rider heights on our product details page. Additionally, we offer free test rides at our physical locations. You can find the specific test ride locations on our 'test ride' page.
