Adjust the Handlebar

Table of Contents

  1. Adjust the Handlebar Angel
    1. Tools Needed
      1. 5mm Allen Wrench
  2. Adjust the Handlebar Angel
    1. 1. Loosen the four fixed bolts of the stem.
    2. 2. Adjust the angle.
    3. 3. Re-tighten the four bolts.
    4. Adjust the Handlebar Height
Finding the proper height and angle for your e-bike handlebar can significantly improve your biking adventures. It is essential to keep in mind that there is not a definitive "correct" or "incorrect" method to adjust the handlebar on your e-bike as you go through this procedure. Instead, focus on comfort for you!


Adjust the Handlebar Angel

Tools Needed

5mm Allen Wrench

Adjust the Handlebar Angel

1. Loosen the four fixed bolts of the stem.

2. Adjust the angle.

Rotate the handlebars forward or backward to your desired position.
Note:
This will only slightly alter the height of the handlebar, but this will adjust its forward or backward angle.

3. Re-tighten the four bolts.

According to the order shown below 1-3-2-4 (in an X-pattern). Tighten the bolts of the stem. Recommended torque: 2-3N/m.

Adjust the Handlebar Height



Please NOTE that t the handlebar height of the eXplorer is not adjustable, and the headset's position is also non-adjustable.

The headset/stem height is fixed during design. The spacers located below the stem must remain below the stem. Recklessly changing the stem position by adding spacers underneath will result in the inability to securely tighten the stem on the fork's steerer tube.

Updated on 11 Dec 2023
